The REEFE VSRE50-175 is a variable speed multistage pressure pump designed to deliver efficient, consistent water pressure across a range of domestic, commercial and agricultural applications.

The integrated variable speed drive automatically responds to changing water demand, helping maintain consistent pressure while reducing unnecessary energy use. With a rated flow of 88 LPM at 41m head and a maximum flow of 175 LPM, the VSRE50-175 is suited to applications requiring water supply for approximately 8–14 taps.

Applications

• Whole-house water supply
• Amenities blocks
• Hotels and restaurants
• Irrigation supply
• Mains pressure boosting
• Stock watering systems

Features & Benefits

• Variable speed operation responds to changing water demand
• Highly efficient, energy-saving design
• Heavy-duty construction for extended service life
• Externally ventilated motor for improved heat management
• Automatic restart following loss of prime
• Certified to AS/NZS 4020 for potable water applications
• Maximum water temperature of 35°C
• Thermal overload protection
• Quick Plug connection
• Supplied with a pressure tank
• IP44 protection and Class F insulation

Specifications

• Rated Flow: 88 LPM
• Rated Head: 41m
• Maximum Flow: 175 LPM
• Maximum Head: 50m
• Recommended Number of Taps: 8–14
• Motor Input (P1): 2.05kW
• Motor Output (P2): 1.1kW
• Supplied VSD Drive: VSC1-12
• Voltage: 240V
• Current: 9A
• Inlet: 32mm / 1¼"
• Outlet: 32mm / 1¼"
• Cable Length: 1.5m
• Weight: 16.45kg
• Dimensions (L × W × H): 436 × 260 × 582mm
• Maximum Water Temperature: 35°C
• Ingress Protection: IP44
• Insulation Class: F

Construction

• Stainless steel AISI 304 pump body and impeller
• Stainless steel AISI 416 shaft
• Carbon-graphite mechanical seal
• Thermal overload protection
• Noryl/fibreglass impellers and diffusers
• Quick Plug connection
• Pressure tank supplied
• IP44 protection
• Class F insulation

Product Details

• Model: VSRE50-175
• Product Number: 21668
